Center Tapped Step Down Transformer In Sinhala

Step down transfomer එකක් යොදාගෙන 12V DC ජව සැපයුමක් සාදා ගැනීම.

Transformers are of two types :
-Step up
-Step down

In this we are dealing with step down transformers,basically step down transformers convert a high voltage to a low voltage

Here we are using a 12V X 2 center tapped transformer (300mA)
the input voltage of the transformer is 230V the input wires are denoted by red color in this case the output side wires are easy to be recognized as there are 3 wires (2 black wires & 1 yellow wire)

The voltage between the yellow wire and any black wire is 12V &
the voltage betweeen the two black wires is 24V.
These transformers can be used for many applications such as construction of power supplies in the upcomming videos we are going to use this transformer to construct a 0 - 12V variable power supply.

The input is connect to the mains via a plug top and 2 wires
the soldering of the wires are insulated by using heat sleeve and insulation tape.

PDF Download - https://drive.google.com/open?id=0B-x...
