Fixed resistors

Fixed resistors In Sinhala

Fixed resistors පිළිබඳ සරල සිංහලෙන් දැනගමු!

Resistance is the opposition for the current flow.
Resistance is measured in ohms (?)
Resistance can be measured from the multimeter directly.

Steps :
Set the multimeter to the resistance range.
Connect the resistor to the multimeter leads.
Take the reading on the display.
Resistance of the resistor can also be calculated using the colour bands printed on the surface of the resistor:

Steps :
Observe the 1st 3 color bands of the resistor (starting from the opposite end to silver or gold color band)
Each colour represents a number.
Black-0
Brown-1
Red-2
Orange-3
Yellow-4
Green-5
Blue-6
Violet-7
Gray-8
White-9
Combining the numbers we can calculate the resistance value as shown in the photo.
The 4th color band gives the tolerance of the resistor.
Silver represents a tolerance of +/-10%
Gold represents a tolerance of +/-5%



Presentation : https://drive.google.com/drive/folders/0B-xkwb9ASKxXS1JTRkZaME5tQXM
Video : https://www.youtube.com/watch?v=NVCuLJA7nRk
FB Page : https://www.facebook.com/vikilabs17/?fref=ts
